Waldorf Blofeld MIDI CC Chart

Back to Synth Docs

View the table below or download the CSV or XLSX files to keep a local copy for quick reference in the studio or on stage.

Related Products

Waldorf Blofeld MIDI CC Chart | Use Shift + Mousewheel or Swipe to scroll horizontally.

cc# parameter_name cc min value cc max value orientation notes
0 Bank select MSB 0 127 standard CC32 supplies the Bank Select LSB.
1 Mod wheel 0 127 standard
2 Breath control 0 127 standard
4 Foot control 0 127 standard
5 Glide rate 0 127 standard
7 Channel volume 0 127 standard
10 Pan 0 127 centered
12 Arpeggiator range 0 9 standard 0~9: 1 to 10 octaves.
13 Arpeggiator length 0 15 standard 0~15: 1 to 16 steps.
14 Arpeggiator active 0 3 standard 0: Off; 1: On; 2: One shot; 3: Hold.
15 LFO 1 shape 0 5 standard 0: Sine; 1: Triangle; 2: Square; 3: Sawtooth; 4: Random; 5: S&H.
16 LFO 1 speed 0 127 standard
17 LFO 1 sync 0 1 standard 0: Off; 1: On.
18 LFO 1 delay 0 127 standard
19 LFO 2 shape 0 5 standard 0: Sine; 1: Triangle; 2: Square; 3: Sawtooth; 4: Random; 5: S&H.
20 LFO 2 speed 0 127 standard
21 LFO 2 sync 0 1 standard 0: Off; 1: On.
22 LFO 2 delay 0 127 standard
23 LFO 3 shape 0 5 standard 0: Sine; 1: Triangle; 2: Square; 3: Sawtooth; 4: Random; 5: S&H.
24 LFO 3 speed 0 127 standard
25 LFO 3 sync 0 1 standard 0: Off; 1: On.
26 LFO 3 delay 0 127 standard
27 OSC 1 octave 16 112 centered 16~112: 128' to 1/2'.
28 OSC 1 semitone 52 76 centered 52~76: -12 to +12.
29 OSC 1 detune 0 127 centered
30 OSC 1 FM 0 127 standard
31 OSC 1 shape 0 5 standard 0: Pulse; 1: Saw; 2: Triangle; 3: Sine; 4: Alt 1; 5: Alt 2.
33 OSC 1 pulsewidth 0 127 standard
34 OSC 1 PWM 0 127 centered
35 OSC 2 octave 16 112 centered 16~112: 128' to 1/2'.
36 OSC 2 semitone 52 76 centered 52~76: -12 to +12.
37 OSC 2 detune 0 127 standard
38 OSC 2 FM 0 127 standard
39 OSC 2 shape 0 5 standard 0: Pulse; 1: Saw; 2: Triangle; 3: Sine; 4: Alt 1; 5: Alt 2.
40 OSC 2 pulsewidth 0 127 standard
41 OSC 2 PWM 0 127 standard
42 OSC 3 octave 16 112 centered 16~112: 128' to 1/2'.
43 OSC 3 semitone 52 76 centered 52~76: -12 to +12.
44 OSC 3 detune 0 127 centered
45 OSC 3 FM 0 127 standard
46 OSC 3 shape 0 5 standard 0: Pulse; 1: Saw; 2: Triangle; 3: Sine; 4: Alt 1; 5: Alt 2.
47 OSC 3 pulsewidth 0 127 standard
48 OSC 3 PWM 0 127 centered
49 Sync 0 1 standard 0: Off; 1: On.
50 Pitchmod 0 127 centered
51 Glide mode 0 9 standard
52 OSC 1 level 0 127 standard
53 OSC 1 balance 0 127 centered
54 Ringmod level 0 127 standard
55 Ringmod balance 0 127 centered
56 OSC 2 level 0 127 standard
57 OSC 2 balance 0 127 centered
58 OSC 3 level 0 127 standard
59 OSC 3 balance 0 127 centered
60 Noise level 0 127 standard
61 Noise balance 0 127 centered
62 Noise color 0 127 standard
64 Sustain pedal 0 127 standard
65 Glide active 0 127 standard
66 Sostenuto 0 127 standard
67 Filter Routing 0 1 standard 0: Parallel; 1: Serial.
68 Filter 1 type 0 10 standard 0: Bypass; 1: LP 24dB; 2: LP 12dB; 3: BP 24dB; 4: BP 12dB; 5: HP 24dB; 6: HP 12dB; 7: Notch 24dB; 8: Notch 12dB; 9: Comb; 10: PPG LP.
69 Filter 1 cutoff 0 127 standard
70 Filter 1 resonance 0 127 standard
71 Filter 1 drive 0 127 standard
72 Filter 1 keytrack 0 127 standard
73 Filter 1 envelope amount 0 127 centered
74 Filter 1 envelope velocity 0 127 centered
75 Filter 1 cutoff modulation 0 127 centered
76 Filter 1 FM 0 127 standard
77 Filter 1 pan 0 127 centered
78 Filter 1 pan modulation 0 127 centered
79 Filter 2 type 0 10 standard 0: Bypass; 1: LP 24dB; 2: LP 12dB; 3: BP 24dB; 4: BP 12dB; 5: HP 24dB; 6: HP 12dB; 7: Notch 24dB; 8: Notch 12dB; 9: Comb; 10: PPG LP.
80 Filter 2 cutoff 0 127 standard
81 Filter 2 resonance 0 127 standard
82 Filter 2 drive 0 127 standard
83 Filter 2 keytrack 0 127 standard
84 Filter 2 envelope amount 0 127 centered
85 Filter 2 envelope velocity 0 127 centered
86 Filter 2 cutoff modulation 0 127 centered
87 Filter 2 FM 0 127 standard
88 Filter 2 pan 0 127 centered
89 Filter 2 pan modulation 0 127 centered
90 Amp volume 0 127 standard
91 Amp velocity 0 127 centered
92 Amp modulation 0 127 centered
93 FX 1 mix 0 127 standard
94 FX 2 mix 0 127 standard
95 Filter envelope attack 0 127 standard
96 Filter envelope decay 0 127 standard
97 Filter envelope sustain 0 127 standard
98 Filter envelope decay 2 0 127 standard
99 Filter envelope sustain 2 0 127 standard
100 Filter envelope release 0 127 standard
101 Amp envelope attack 0 127 standard
102 Amp envelope decay 0 127 standard
103 Amp envelope sustain 0 127 standard
104 Amp envelope decay 2 0 127 standard
105 Amp envelope sustain 2 0 127 standard
106 Amp envelope release 0 127 standard
107 Envelope 3 attack 0 127 standard
108 Envelope 3 decay 0 127 standard
109 Envelope 3 sustain 0 127 standard
110 Envelope 3 decay 2 0 127 standard
111 Envelope 3 sustain 2 0 127 standard
112 Envelope 3 release 0 127 standard
113 Envelope 4 attack 0 127 standard
114 Envelope 4 decay 0 127 standard
115 Envelope 4 sustain 0 127 standard
116 Envelope 4 decay 2 0 127 standard
117 Envelope 4 sustain 2 0 127 standard
118 Envelope 4 release 0 127 standard
120 All sound off 0 127 standard
121 Reset all controllers 0 127 standard
122 Local control on/off 0 127 standard
123 All notes off 0 127 standard

See something wrong? Please email us with any corrections.
